100% New Highly Integrated VCO with Buffer Amplifier For 3dBm 110-170MHz Electronic Parts Voltage Controlled Oscillator

Name: 100 New Highly Integrated VCO with Buffer Amplifier For 3dBm 110170MHz Electronic Parts Voltage Controlled Oscillator
Brand: RFint
Price: 1 USD

Quality 100% New Highly Integrated VCO with Buffer Amplifier For 3dBm 110-170MHz Electronic Parts Voltage Controlled Oscillator wholesale

Place of Origin : Jiangsu, China

Brand Name : RFint

Model Number : YSGM111704D

Price : Prices are negotiable

Packaging Details : Opp bag

Delivery Time : 2-10days

Payment Terms : T/T,Western Union,MoneyGram

Specification : Standard

Packaging Type : opp bag

Application : 110-170MHz

Package / Case : Standard

Series : VCO

Features : Standard

Size / Dimension : 7mm*9mm*2mm

Description : High integration Voltage Controlled Oscillator

Manufacturing Date Code : Other

Nominal tuning frequency band : 110 ~ 170MHz@VT=0V~5V

Output power : ≥3dBm @VCC=5V

Power supply voltage (VCC) : 3V ~ 6V

Working current : 12mA(VCC=5V)

Universal package size : 7mm*9mm*2mm

Contact Now

100% New Highly Integrated VCO with Buffer Amplifier For 3dBm 110-170MHz Electronic Parts Voltage Controlled Oscillator

Product Description

YSGM111704D is a highly integrated, standard packaged broadband voltage-controlled oscillator (VCO) product. The improved Colpitts oscillation circuit structure and integrated buffer buffer are adopted, which has the advantages of stable oscillation, good isolation and high output power.

Nominal tuning frequency band	110 ~ 170MHz@VT=0V~5V
Output power	≥3dBm @VCC=5V
In-band flatness (BW≤200MHz)	±1.5dB
Power supply voltage (VCC)	3V ~ 6V
Working current	12mA
Second harmonic suppression	≤-10dBc
Third harmonic suppression	≤-20dBc
Radio-frequency output impedance	50Ω
Universal package size	7mm x 9mm x 2mm

100% New Highly Integrated VCO with Buffer Amplifier For 3dBm 110-170MHz Electronic Parts Voltage Controlled Oscillator

Packing & Delivery

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.

Company Profile

Zhongshi Zhihui Technology (suzhou) Co., Ltd. is located in Suzhou Industrial Park, founded in 2010, the company is mainly engaged in, and can provide customers with wireless communication network coverage solutions of high-tech enterprises. The company implements radio-oriented development strategy based on radio frequency technology, independent research and development and production of bidirectional frequency conversion super WiFi signal amplifier products, radio frequency and microwave voltage controlled oscillator (VCO), sweep signal source, wireless network card information security module and other product lines, has mastered some core technologies in the product field, has a lot of independent intellectual property rights.

FAQ

1. who are we?
We are based in Jiangsu, China, start from 2010,sell to Western Europe(50.00%),Southern Europe(12.00%).

2. how can we guarantee quality?
Always a pre-production sample before mass production;

Always final Inspection before shipment;

1 year warranty for our products.

3.what can you buy from us?
Signal Booster, VCO, Anti Drone Jammer Module, Power Amplifier, Gain Block and so on

100% New Highly Integrated VCO with Buffer Amplifier For 3dBm 110-170MHz Electronic Parts Voltage Controlled Oscillator Images
